Shars 3 90 Degree Square Shoulder Indexable Face Mill With 7 Pcs APKT1604 Carbide Insert 404-1869W+404-6541(7) P[

Shars Tool 3 90 degree Face Mill with APKT Insert Benefit from the 90-degree lead angle allows efficient square shoulder milling and the ability to machine workpieces with weak structures or thin walls over a 45-degree face mill. It uses an industry-standard APKT/APMT 1604 insert with a positive 11-degree clearance angle and depth of cut of 0.551 or 14mm. Fitted with 10-degree positive rectangular inserts allow the high depth of cut and feed per tooth Setting Angle: 90 degree Radial rake angle: -10 degree Axial rake angle: +7 degree Product Included Insert screw & wrench 7 PCS of APKT1604 Carbide Inserts (SKU#404-6541) Technical Specs Part# 404-1869W Cutting Diameter D: 3 Arbor Hole Diameter d: 1 Overall Height H: 2 Insert: APKT1604 Number of Flutes 7 Screw: M4x10 Product Spotlight An easy reference guide for insert number, screw, and other accessories is printed on the tool To be used on: Alloy Steel, Stainless Steel Application: Semi-Finish ANSI Number: APKT33PDER-PM ISO Number: APKT160408PM Coating: PVD Nc-TiAlN Insert Measurement Length: 0.704; Width: 0.367 Thickness: 0.227; Through Hole: 0.173 Corner Radius: 1/32 Suitable for most face-milling applications Chip thinning effect allows for increased table feeds High Positive cutting geometry Cutting Diameter: 3; Arbor Hole: 1 Included 7 PCS APKT1604 Inserts
