ZTW Beatles G2 20A ESC 2-4S SBEC For RC Airplane Fixed-wing

These must-have brushless speed controllers provide smooth and accurate throttle linearity for all your flights. /𝗣𝗲𝗮𝗸 𝗖𝘂𝗿𝗿𝗲𝗻𝘁: 20A/30A ●𝗜𝗻𝗽𝘂𝘁 𝗩𝗼𝗹𝘁𝗮𝗴𝗲: 2-4S LiPo ●𝗕𝗘𝗖 𝗢𝘂𝘁𝗽𝘂𝘁: 5V/6V 4A ●𝗜𝗻𝗽𝘂𝘁 𝗖𝗼𝗻𝗻𝗲𝗰𝘁𝗼𝗿𝘀: XT60 (Male) ●𝗢𝘂𝘁𝗽𝘂𝘁 𝗖𝗼𝗻𝗻𝗲𝗰𝘁𝗼𝗿𝘀: 3.5mm Gold Connectors (Female) ●𝗟𝗲𝗻𝗴𝘁𝗵: 59mm/2.32in ●𝗪𝗶𝗱𝘁𝗵: 26.2mm/1.03in ●𝗛𝗲𝗶𝗴𝗵𝘁: 9.2mm/0.36in ●𝗪𝗲𝗶𝗴𝗵𝘁: 33.6g 𝐒𝐄𝐓𝐓𝐈𝐍𝐆𝐒: ●𝗦𝗠𝗥 (𝗦𝘄𝗶𝘁𝗰𝗵 𝗠𝗼𝘁𝗼𝗿 𝗥𝗼𝘁𝗮𝘁𝗶𝗼𝗻) 𝗙𝘂𝗻𝗰𝘁𝗶𝗼𝗻: *𝗢𝗙𝗙/ON ●𝗕𝗿𝗮𝗸𝗲 𝗧𝘆𝗽𝗲: *𝗢𝗙𝗙/Soft Brake/Mid Brake/Hard Brake ●𝗠𝗼𝘁𝗼𝗿 𝗧𝗶𝗺𝗶𝗻𝗴: *𝗔𝘂𝘁𝗼/Low/Mid/High ●𝗠𝗼𝘁𝗼𝗿 𝗥𝗼𝘁𝗮𝘁𝗶𝗼𝗻: *𝗖𝗪/CCW ●𝗦𝗥 (𝗦𝘆𝗻𝗰𝗵𝗿𝗼𝗻𝗼𝘂𝘀 𝗥𝗲𝗰𝘁𝗶𝗳𝗶𝗰𝗮𝘁𝗶𝗼𝗻) 𝗙𝘂𝗻𝗰𝘁𝗶𝗼𝗻: ON/*𝗢𝗙𝗙 ●𝗕𝗮𝘁𝘁𝗲𝗿𝘆 𝗖𝗲𝗹𝗹𝘀: *𝗔𝘂𝘁𝗼/2S/3S/4S ●𝗟𝗼𝘄 𝘃𝗼𝗹𝘁𝗮𝗴𝗲 𝗖𝘂𝘁𝗼𝗳𝗳 𝗧𝗵𝗿𝗲𝘀𝗵𝗼𝗹𝗱: OFF/NIMH50%/NIMH60%/*𝟯.𝟬𝗩/3.2V/3.6V ●𝗟𝗼𝘄 𝘃𝗼𝗹𝘁𝗮𝗴𝗲 𝗖𝘂𝘁𝗼𝗳𝗳 𝗧𝘆𝗽𝗲: *𝗥𝗲𝗱𝘂𝗰𝗲 𝗣𝗼𝘄𝗲𝗿/Cut off Power ●𝗕𝗘𝗖 𝗩𝗼𝗹𝘁𝗮𝗴𝗲: *𝟱𝗩/6V ●𝗔𝗰𝗰𝗲𝗹𝗲𝗿𝗮𝘁𝗶𝗼𝗻: *𝗡𝗼𝗿𝗺𝗮𝗹/Soft The options marked with “*” are the factory default settings. High-performance 32-bit microprocessor, compatible with various brushless motors. High-power switch mode BEC with 5V/6V 4A output, employ more electronic devices, such as receivers and servos. Pre-installed XT60 connector for the battery and 3.5mm gold connectors for the motor, no soldering is required. Power on protection, over-heat protection, low-voltage protection and lost-signal protection.
